Sparta PN3079 Fuel Pump Module Assembly

Fuel Pump Module Assembly for 2004 Pontiac Grand Prix

Sparta PN3079 is a specific-fit in-tank fuel pump module assembly for the 2004 Pontiac Grand Prix. Built as a standard replacement, it combines the pump, sending unit, regulator, strainer, gasket, and wiring harness components needed for a complete fuel delivery service.

Key Features

• Specific-fit fuel pump module assembly for the 2004 Pontiac Grand Prix
• 12-volt electric turbine pump design for gasoline applications
• Includes fuel sending unit, regulator, strainer, gasket/seal, and wire harness
• In-tank configuration with quick-connect outlet and oval female connector
• Fuel tank pressure sensor included
• Standard replacement design from Sparta, distributed by Delphi
• Part number PN3079 for ordering and cross-reference lookup

Detailed Description

Sparta PN3079 is engineered for higher-mileage and earlier-model vehicles, with OE-informed fit and performance support from Delphi’s fuel system expertise. This fuel pump module assembly is designed for gasoline use and installs inside the tank, using a turbine-style electric pump with a 58 to 80 psi pressure range and an average flow rating of 17. The module includes a 4-wire harness, 4-pin male terminals, a quick-connect outlet, and a nitrile rubber gasket/seal for service replacement. PN3079 also includes the fuel sending unit and fuel tank pressure sensor, helping restore accurate fuel level reporting and stable fuel delivery on the Pontiac Grand Prix.

This part cross-references Carter P76136M and Autobest F2575A for the same application. Search PN3079 when sourcing a fuel pump module assembly for the 2004 Pontiac Grand Prix.

What It Helps Address

• Hard starting caused by weak or inconsistent fuel pressure
• Engine stalling from fuel delivery interruption
• Incorrect fuel gauge readings from a worn sending unit
• Fuel pressure regulation issues inside the tank module
• Fuel tank sensor faults tied to the module assembly

Installation Notes and Tips

Verify the tank opening, connector style, and outlet configuration before installation. This module is specific fit and uses a quick-connect outlet with an oval connector, so matching the original layout is important. The package includes a seal, splice kit, and instruction sheet; mounting hardware and lock ring are not included. Clean the tank area thoroughly before installation and confirm the electrical connections are secure before reassembly.

Quality Assurance

Sparta fuel system components are backed by Delphi distribution and OE-focused engineering knowledge. PN3079 is a standard replacement fuel pump module assembly built for fitment accuracy and dependable fuel delivery on the 2004 Pontiac Grand Prix.
